I am able to successfully ping and telnet from a remote device through the router asa5520 vpn tunnel into the hq hosts so i can see communication is working initial isakmp negotiation debugs on router below shows the differences but the asa accepts anyway.
Vpn tunnel or transport mode. Ipsec vpn modes tunnel mode and transport mode ipsec can be used to create vpn tunnels to end to end ip traffic also called as ipsec transport mode or site to site ipsec tunnels between two vpn gateways also known as ipsec tunnel mode. Virtual private networks vpns make use of tunnel mode where hosts on one protected network send packets to hosts on a different protected network via a pair of ipsec peers such as cisco routers. Each of these modes has its own particular uses and care should be taken to ensure that the correct one is selected for the solution.
Tunnel mode encapsulates the whole ip packet by either encrypting authenticating or most likely doing both. The ipsec transport mode is implemented for client to site vpn scenarios. If ipsec is required to protect traffic from hosts behind the ipsec peers tunnel mode must be used.
Deciding which ipsec mode to use depends dramatically on your network topology and the purpose of your vpn. Tunnel mode will encapsulate our packets with ipsec headers and trailers. Tunnel mode encrypts the whole packet and is used for the establishment of site to site vpn tunnels when securing communication between vpn gateway devices.
You will not see difference between transport mode vs tunnel mode. When using encapsulating security payload esp you can specify one of two modes in which esp operates in which are tunnel mode or transport mode. Tunnel mode is most commonly used between gateways cisco routers or asa firewalls or at an end station to a gateway the gateway acting as a proxy for the hosts behind it.
Esp and ah are used. Transport mode actually is recommended mode for dmvpn because it saves 20 bytes overhead. Tunnel mode provides security for the entire original ip packet protecting the headers and payload.
So the ip header of the original packet is not encrypted. Tunnel mode is most commonly used between gateways or at an end station to a gateway the gateway acting as a proxy for the hosts behind it. Mss is higher when compared to tunnel mode as no additional headers are required.
